小型基本 |
|
Bore |
ØA |
B |
C |
D |
E |
F |
G |
L |
MM |
N |
ØO |
ØX |
U |
W |
PT |
|
Ø20 |
12 |
M10×P1.5 |
32 |
20 |
14 |
22 |
22 |
40 |
M22×P1.5 |
16 |
30 |
10 |
14 |
12 |
1/8" |
|
Ø25 |
14 |
M12×P1.75 |
36 |
20 |
16 |
24 |
24 |
44 |
M30×P1.5 |
16 |
35 |
12 |
14 |
13 |
1/8" |
|
Ø30 |
18 |
M16×P1.5 |
40 |
25 |
16 |
24 |
24 |
54 |
M35×P1.5 |
22 |
40 |
12 |
16 |
13 |
1/4" |
|
Ø40 |
20 |
M18×P1.5 |
50 |
25 |
20 |
32 |
32 |
54 |
M40×P1.5 |
22 |
50 |
16 |
20 |
18 |
1/4" |
|
