閥體材質： |
銅（BRONZE） |
|
通過直徑： |
DN15mm∼50mm |
|
氣缸啟動壓力： |
4∼8bar |
|
溫度： |
-20℃∼+180℃ |
|
|
a |
G |
A |
B |
C |
d |
E |
Ch |
PESO |
|
mm. |
|
mm. |
mm. |
mm. |
mm. |
mm. |
mm. |
gr. |
|
15 |
1/2" |
225 |
186 |
60 |
19 |
97 |
27 |
1400 |
|
20 |
3/4" |
230 |
188 |
70 |
24 |
97 |
32 |
1550 |
|
25 |
1" |
243 |
195 |
80 |
31 |
97 |
41 |
1800 |
|
32 |
1"1/4 |
294 |
239 |
96 |
39 |
115 |
50 |
3150 |
|
40 |
1"1/2 |
304 |
246 |
105 |
45 |
115 |
56 |
3250 |
|
50 |
2" |
319 |
253 |
130 |
57 |
115 |
70 |
4150 |
|
